| Hi-Current Power Female 2PW+4S Straight Type | |
| 小型大电流连接器母座 2组电源+4个信号 直立式 | |
| 电压 Voltage rating | 250VDC max. |
| 电流 Current rating | 60A/Per Power Pair |
| 接触阻抗 Contact resistance | 0.6mΩ max. Initial |
| 耐久 Durability Life | 5,000 cycles max. |
| 应用提示 FAE Tips | Optional Not detrinential of Spark Pin & FMLB & Water-Proof 可选：无害打火、先接触后断开信号侦测和防水结构 |
| 工作温度 Working Temps | -40°C~125°C. |
| 应用领域 Application Field | UAV/Robot/IE… |
| Hi-Current Power Female 2PW+4S Straight Type | |
| 小型大电流连接器母座 2组电源+4个信号 直立式 | |
| 电压 Voltage rating | 250VDC max. |
| 电流 Current rating | 60A/Per Power Pair |
| 接触阻抗 Contact resistance | 0.6mΩ max. Initial |
| 耐久 Durability Life | 5,000 cycles max. |
| 应用提示 FAE Tips | Optional Not detrinential of Spark Pin & FMLB & Water-Proof 可选：无害打火、先接触后断开信号侦测和防水结构 |
| 工作温度 Working Temps | -40°C~125°C. |
| 应用领域 Application Field | UAV/Robot/IE… |
